•120 VAC, 60 Hz,
•Input Fuse: 2 Amp Fuse @ 250VAC
•2A @ 24VDC
•2 Solid State I/O’s - 1 A auto resetting fused outputs
•Power tap: .5A @ 24VDC
•Over-voltage protection
•Output Voltage trim pot
•Regulated, independent battery charging
•Automatic uninterrupted backup circuit
•Battery cables included
•Requires (2) 12VDC 7AH batteries
•Batteries not included
•Fire alarm link
•Red = A/C Power indicator
•Green = D/C Output indicator
•Orange = Battery Output Indicator
•Linear design insures ample inrush/hold currentfor latch retraction
•Door mounted LED Power Indicator
•Easy to remove euro connectors
•UL294 6th Edition
•Enclosure dimensions: PS220 (11” W x 11” H x 4”D). PS220B (13” W x 15.5” H x 5” D).
•1/2” & 3/4” knockouts on all sides
•Hinge-less removable cover; Cam lock notprovided
•PS220B accommodates (2) 12VDC 7 aH batteries
•Product Weight: - 10lbs
•Shipment Weight: PS220 - 11lbs
•Temperature range: 0 to 49° C; 32 to 120° F
•Maximum humidity: 85%
•120 VAC, 60 Hz,
•Input Fuse: 2 Amp Fuse @ 250VAC
•2A @ 24VDC
•2 Solid State I/O’s - 1 A auto resetting fused outputs
•Power tap: .5A @ 24VDC
•Over-voltage protection
•Output Voltage trim pot
•Regulated, independent battery charging
•Automatic uninterrupted backup circuit
•Battery cables included
•Requires (2) 12VDC 7AH batteries
•Batteries not included
•Fire alarm link
•Red = A/C Power indicator
•Green = D/C Output indicator
•Orange = Battery Output Indicator
•Linear design insures ample inrush/hold currentfor latch retraction
•Door mounted LED Power Indicator
•Easy to remove euro connectors
•UL294 6th Edition
•Enclosure dimensions: PS220 (11” W x 11” H x 4”D). PS220B (13” W x 15.5” H x 5” D).
•1/2” & 3/4” knockouts on all sides
•Hinge-less removable cover; Cam lock notprovided
•PS220B accommodates (2) 12VDC 7 aH batteries
•Product Weight: - 10lbs
•Shipment Weight: PS220 - 11lbs
•Temperature range: 0 to 49° C; 32 to 120° F
•Maximum humidity: 85%
A-PS-220B - 110-120VAC input power supplies that deliver (2) amps @ 24VDC to (2) PTC fused outputs. (2) solid-state input triggers, protects system relays from shorts, grounds and surges. Its linear design makes it a perfect match for solenoid & motor driven exit devices, electric locks, electric strikes, and mag locks.
